mart 16” Display Specifications
✔ Full HD resolution (1920×1080) for ultra-clear image and video playback
✔ Wide 89° viewing angle for comfortable viewing from any direction
✔ Advanced content management with auto-play and remote scheduling
✔ WiFi + Ethernet connectivity for flexible data transfer and updates
✔ Android 7.1 operating system with quad-core processor for smooth performance
✔ Built-in 5W ×2 speakers for enhanced audio quality
✔ Smart statistics and playback reports to monitor content performance
✔ Operates under tough conditions, with temperature range from 0°C to 70°C
🖥 Ideal for businesses, retail, meeting rooms, and smart restaurants
📺 Display Specifications:
- Size: 16 inches (diagonal)
- Aspect Ratio: 16:9
- Resolution: 1920×1080 (Full HD)
- Viewing Angle: 89° in all directions
- Color Depth: 16.7 million colors
- Contrast Ratio: 1000:1
- Brightness: 300 cd/m²
- Response Time: 8 ms
🔊 Power & Audio:
- Power Input: DC 10–36V
- Power Consumption: 13W
- Speakers: Built-in 5W ×2
📁 Supported Media Formats:
- Audio: MP3, WMV
- Images: JPEG, BMP, GIF
- Video: MPEG-1, MPEG-2, MPEG-4, AVI, MKV, FLV, VOB, TS
🧠 Storage & Processing:
- Operating System: Android 7.1
- RAM: 1GB DDR3
- Internal Storage: 32GB eMMC
- CPU: A40 ARM Cortex-A17, quad-core, 1.2GHz
- GPU: ARM Mali-400
🌐 Connectivity:
- Wired: RJ45 Ethernet port (100 Mbps)
- Wireless: WiFi 2.4G (802.11b/g/n)
📽 Multimedia Playback Features:
- Loop playback / Slideshow
- Background music mode
- Multi-display (image + video + scrolling text simultaneously)
- Auto-play on startup
📊 Content Management:
- Auto-update via USB to SD
- Remote control: program scheduling, volume control, on/off timers
- Role-based content permissions (grouping, multi-level approvals)
- Smart analytics (media playback logs)
🔐 Security:
- Built-in security lock to protect media content
🌡 Environmental Conditions:
- Storage Temperature: -20°C to 60°C
- Operating Temperature: 0°C to 70°C
- Humidity: 10% to 90%
